Specifications
| Input Impedance | 1 MOhm (pad at 0dB), 47 kOhm (pad at -20dB or -40dB) |
| Max Input | +9dBu (pad at 0dB), +29dBu (pad at -20dB), +49dBu (pad at -40dB) |
| Input Connectors | Two Parallel 1/4″ jack connectors (Tip Hot +ve, Sleeve ground), and a parallel XLR connector (unbalanced) (Pin 2 Hot +ve, Pin 1 & 3 ground) |
| Output | Transformer Balanced |
| Max Output | +8dBu into 600 Ohms or greater |
| Output Connectors | XLR3-32 or equivalent |
| THD | < 0.005% at 1khz, 0dbu output |
| Noise | < -105db unweighted, 22hz-22khz, rms* |
| Frequency Response | 30Hz to 20kHz, +0dB/-1dB |
| Main/Standby battery | 9 volt PP3 type, preferably alkaline |
| Power Consumption | on phantom: less than 7.5mA, on battery: less than 2mA. |
| Phantom Power | +20 volts DC to +48 volts DC |
| Unit Weight | 650 gms, excluding batteries |
| Dimensions | 59 mm x 124 mm x 143 mm (2.3″ x 4.9″ x 5.6″) |
