dbx 234xs crossover

dbx 234xs crossover Features

• 2-/3-way stereo, 4-way mono operation
• 24dB/octave Linkwitz-Riley filters
• XLR inputs and outputs
• Low-frequency summing for subwoofer output
• x10 range switch on both channels
• 40Hz highpass (low cut) filter both channels
• Phase reverse switch on all outputs
• Individual level controls on all outputs
• Stereo/Mono status LEDs indicate the selected mode
• dbx 2-year parts and labor coverage
• Number of Channels:2
• Modes:2-way (Stereo), 3-way (Stereo), 4-way (Mono)
• Filter Types:Linkwitz-Riley
• Filters:24dB/octave
• Crossover Frequencies – Stereo:45Hz-960Hz/450Hz-9.6 kHz
• Crossover Frequencies – Mono:45Hz-960Hz/450Hz-9.6 kHz
• Inputs:2 x XLR
• Outputs:6 x XLR
• Rack Spaces:1U
